Bluetooth Mobile Phone PDA Industrial with Magnetic Charging , Back Clip Functional Options

Product Categories

Beijing Speedata Technology Co., Ltd

Contact Now

Bluetooth Mobile Phone PDA Industrial with Magnetic Charging , Back Clip Functional Options

Ask Lasest Price
Brand Name :	Speedata
Model Number :	KT55-S
Certification :	CE,ISO9001,IP65, 3C
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	5000pcs/month
Delivery Time :	5-8working days

Add to Cart

Product Details
Company Profile

Bluetooth Mobile Phone PDA Industrial with Magnetic Charging , Back Clip Functional Options

Bluetooth Mobile Phone PDA Industrial with Magnetic Charging , Back Clip Functional Options

Features:

Rugged High Performace Industrial Harware Solutions

Applications of KT55 Android 5.1 Barcode Scanner:

Express and Logistics
Warehouse & Inventory
Mobile Sales Management
Retail Chain in Supermarket
Cargo Management
Information Tracking

SPECIFICATION

KT55 Android Device with 2D Barcode
OS		Android 5.1
CORE
Core	CPU	Octa-core 1.3GHz ARM® Cortex-A53
	WWLAN	FDD B1B3B7 TDD B38B39B40 WCDMA B1B2B5B8 EVDO BC0 GSM B2B3B5B8
	Flash ROM	16GB
	RAM	2GB DDR3
General Configuration
Display	Main Screen	5.5 inch OLED 1920*1080 FHD
Display	Sub-screen	0.91 OLED
Touch screen		Multi-point touch capacitive screen
Fingerprint		Yes
GPS		Support GPS/QZSS/SBAS (WAAS/MSAS/EGNOS/GAGAN). Support Full AGPS
Bluetooth		v2.1+EDR / 3.0+HS / v4.0 Low Energy (LE)
WiFi		802.11 a/b/g/n
Protection class		IP65
Drop resistance level		1.5m
Camera (Yes)	Rear camera	13MP Camera
Camera (Yes)	Front camera	5MP Camera
Keypad	Front /Side	5 side buttons

Interface	Micro-USB connector	USB2.0 OTG
	SIM card slot	1 standard SIM slot
	SIM card slot	1 Micro SIM slot
	TF card slot	Yes
	power jack	Micro-USB
	Audio Jack	Yes
External Interface	OPTION	USB, RS232, SPI, GPIO

Battery	Type	rechargeable Li-ion battery 6000mAh
	Standby Time	600hours
	Calls Time	Up to 6hours
	Charging Time	5 hours (USB charging)
Physical Characteristics	Dimension	1707913mm
Physical Characteristics	Weight	>250g with battery (according config)

Operating temperature		-20°C to 50°C / -4°F to 122°F
Storage temperature		-30°C to 70°C / -22°F to 158°F
Humidity (non-condensed)		Operating 10% to 90% / Storage 5% to 95%
Electrostatic discharge		± 15 kV air discharge, ± 8 kV contact discharge
EMC regulation		CE

OPTIONS
Appearance color	option	various color options
Wireless charging	option	include Wireless transmitting base.
Far Infrared Meter Reading	option	IEC62056-21(IEC1107) communication protocol
IRIS recognition	option	The recognition distance is less than 20cm
PSAM	option	ISO7816 (SIM card interface)
NFC	option	NFC(Compatible 13.56MHz ISO 14443A ISO15693)
Barcode scanner	Yes	Honeywell N6603 1D & 2D barcode scanner

Clip device
RFID reader	option 1	LF RFID(134.2KHz, ISO11784/11785, FDX-B/HDX) - reading distance 10cm
	option 2	LF RFID(125KHz) - reading distance 10cm
	option 3	HF RFID(13.56MHz ISO 14443A/B ISO 15693)- reading distance 5cm
	option 4	R2000 UHF RFID 860-960MHz ISO18000-6C (EPC Gen2) - reading distance up to 3m-6m
IC card reader(Optional)	option	ISO7816 ID-1
Printer	option	2 inch direct thermal printer
MRZ	option	ICAO Document 9303 / E13B and OCRB fonts
Fingerprint reader	option 1	UPEK TCS1 (meet the FBI’s FIPS-201)
	option 2	UPEK TCS2SS
	option 3	Customized according to customer needs.
Free Extension		Multiple extension interface, such as RS232, GPIO, USB, SPI. You can freely design what you want.
