    Mobile Handheld PDA Thermal Printer With Wifi Bluetooth GPRS GPS for Railway ticket

    Ask Lasest Price
    Brand Name : Speedata
    Model Number : KT45-B2-C8M-PE48
    Certification : ISO9001,CCC,CQC,IP65
    Payment Terms : Western Union, MoneyGram,Paypal
    Supply Ability : 5000 pcs per month
    Delivery Time : 3-7 days after payment
    • Product Details
    • Company Profile

    Mobile Handheld PDA Thermal Printer With Wifi Bluetooth GPRS GPS for Railway ticket

    Mobile Handheld PDA Thermal Printer With Wifi Bluetooth GPRS GPS for Railway ticket
    Product Description->

    KT45-C8M-PE48
    android OS
    OSAndroid 4.4.2
    Hardware
    Core boardCPU Quad-core 1.3Ghz
    ARM® Cortex-A7 MPCoreTM (LPDDR2 and LPDDR3)
    WWLAN GSM band 850/900/1800/1900MHz, Class 12 GPRS, EDGE
    UMTS 850/900/1900/ 2100MHz HSPA
    Flash ROM 8GB
    RAM 1GB DDR3
    Motherboard
    Display4.5inch IPS 480*854
    touch screenMulti-point touch capacitive screen
    Form FactorBar type classical PDA,Industrial appearance
    GPSSupports GPS/QZSS/SBAS (WAAS/MSAS/EGNOS/GAGAN). Support Full AGPS
    Bluetoothv2.1+EDR / 3.0+HS / v4.0 Low Energy (LE)
    WiFi2.4Ghz 802.11 b/g/n
    MSR(Optional)Compatible with one, two, three track. (without PCI, EMV security certification.)
    PSAM(Optional)ISO7816 (SIM card interfance)
    IC card reader(Optional)ISO7816 ID-1
    Fingerprint readeroption 1 UPEK TCS1 (meet the FBI’s FIPS-201)
    option 2 UPEK TCS2SS
    Printer (YES )2 inch Direct thermal line printing
    Far Infrared Meter Reading (Optional)IEC62056-21(IEC1107) communication protocol
    433Mhz module(Optional)Require customers to provide 433Mhz wireless modules or specifications.
    zigbee (Optional)Require customers to provide 433Mhz wireless modules or specifications.
    RFID Readeroption 1 LF RFID(134.2khz, ISO11784/11785, FDX-B/HDX) -- reading distance 10cm
    option 2 LF RFID(125KHz) -- reading distance 10cm
    option 3 HF RFID(13.56MHz ISO 14443A/B ISO 15693) -- reading distance 5cm
    option 4 NFC(include 13.56MHz ISO 14443A/B )
    option 5 UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) / ISO18000-6A,B compatibility in direct mode----with AS3992 shipset -- reading distance up to 3m
    barcode scanneroption 1 NEWLAND:EM1300(1D barcode reader-- Most cheapest )
    option 2 NEWLAND:EM3095(1D/2D barcode reader-- hardware decoding)
    YES symbol:SE955(1D laser barcode reader)
    option 4 Symbol: se4500(1D&2D barcode reader-- software decoding)
    External InterfaceUSB HOST/RS232(Customized)
    Protection classIP65
    Drop resistance level1.5m
    Camera Function8MP Camera
    Support still image and video capture
    SensorLIS3DH
    AK09911C
    MPU3050C
    STK3410
    Keypad17
    4
    InterfaceUSB2.0 connection
    *2
    Yes
    Yes
    Yes
    Batteryrechargeable Li-ion battery 4500mAh
    500hours
    Up to 6hours
    4 hours
    Physical Characteristics175*76*27mm
    >400g with battery (according config)
    Printer Module Specifications
    Printing methodDirect thermal line printing
    Paper width57mm
    Print width48mm
    Resolution Ration8 dots/mm (384 dots/line )
    Life of printing head5,000,000 -15,000,000 character lines
    Printing speed40-60mm/sec
    Character size8*16dots , 12*24dots
    Paper supplied57mm wide , 30mmø
    InterfaceSerial RS232C/TTL
    Operating temperature0℃--50℃
    Storage temperature-20℃ -- 60℃
    Operating humidty10%--80%
    Storage humidty10%--90%


    Our Services->

    As a OEM/ODM and R&D manufacturer of PDA, we support you:

    • Completely Free SDK and technical support for you.
    • ODM/OEM and 6 kinds of customization services according to your needs.
    • 13months warranty for your devices and other parts. and 6 months for the batteries. Exend warranty,it'll cost 0.5% for each per year.
    • Free maintenance of the devices and part of accessories replacement in the warranty .if out of the warranty, you'll have to pay the basic cost for them.
    Company Information->

    Beijing Speedata Technology Co., Ltd (stock code: 832442 ), founded in 2008, is a provider of IoT (Internet of Things) solutions and OEM/ODM manufacturer of wireless hardware terminal and software solution, focusing on such wireless network enabling technologies as 1D/2D Barcode scanner, RFID , 433M, MSR, ZigBee, PSAM, and IC card reader...

    We are headquartered in Beijing, with sales/R&D offices in Shanghai, Shenzhen, Dalian, and Tianjin city of China, and two manufacturing facilities, one in Beijing and one in Tianjin.


    At the same time, we successfully cooperated with Foxconn by OEM/ODM in Shenzhen.


    OEM Service

    1.As a hardware PDA producer, We also offer OEM/ODM design and manufacturing service for hardware required for Data collector terminal PDA, including

    • Brand & Logo
    • Different colors
    • Multiple modules integration
    • Wide industrial and business solutions
    • Competitive and diverse price ranges

    8 years' experience of R&D and OEM/ODM services for customers all over the world.


    2.As for software integration , We not only support 18 kinds of multiple modules but also supply 3 compatible operating systems. Those Including


    • The most popular Android 4.4 and Windows CE or Mobile
    • 1D/2D barcode scanner
    • LF/HF/UHF RFID as well as NFC RFID Function.
    • Biometric fingerprint reader
    • Thermal printer
    • DGPS/ PSAM/ 433M/ IC Card/ MSR/ IR Meter Reading

    FAQ

    Question 1: what's your barcode scanner MOQ?
    Answer: the MOQ of speedata barcode scanner barcode scanner is 1 pcs.

    Question 2: how long is the delivery time?
    Answer: The delivery time of barcode scanner goods is different from quantities:
    If 1~100 pcs, It's about 5--10 working days;
    If 100~500 pcs, it's about 10--20 working days;
    If More than 500 pcs, It's about 20-30 working days.

    Question 3: Would you like to supply 1 sample for testing?
    Answer: Yes, Of course. We can provide 1 sample of barcode scanner PDA for your testing.

    Question 4: What's the total price for 1 sample?
    Answer: As a manufacturer of barcode scanner terminal PDA.the more you buy,the cheaper it'll be.
    the sample price is a little bit higher than the common wholesale price.excluding the freight fee.

    Question 5: Are you a manufacturer of barcode scanner PDA?
    Answer: Yes, we are a chinese listed company of R&D and producing barcode scanner hardware and software. and also we cooperate with Foxconn for OEM.

    Question 6: what kind of services do you support?
    Answer:1.We provide you Free SDK and technical support for your barcode scanner.
    2.we also provide ODM/OEM customization services according to your needs.
    3.We support 13months Warranty for your devices and other parts. and 6 months for the batteries. Exend warranty,it costs 0.5% for each per year.

    Question 7: what's for payment term and delivery term ?
    Answer: 1.It's generally 30%-100% TT in advance for all orders for the payment term.
    with supporting via bank card, Paypal or West Union.
    2.FOB Shenzhen for Delivery term.

    Question 8: who are your customers?
    Answer: 1.That's quiet a serious question, but Our products are sold worldwide in South/North America, Europe, Asia, Africa Mid-east, etc.
    2.The market share is increasing quickly every year and we get great feedback from our customers.
    IF you need more information and details, Please Feel free to contact us. Thanks for your attention.
