Waterproof Industrial Android Barcode Scanners Portable Data
Collection Device for FMCG
| KT40-1D&2D barcode scanner |
Key features
1, Aluminum-magnesium alloy frame. Providing robust protection for
the device.
2, Innovative magnetic attraction charging.
3, Best cost device.
4, Extensions: Ring control barcode scanning.
5, OEM by FOXCONN in Shenzhen. |
| android OS |
| OS | Android 4.4.2 |
| CORE |
| Core board | CPU | Quad-core 1.3Ghz
ARM® Cortex-A7 MPCoreTM (LPDDR2 and LPDDR3) |
| WWLAN | GSM band 850/900/1800/1900MHz, Class 12 GPRS, EDGE
UMTS 850/900/1900/ 2100MHz HSPA |
| Flash ROM | 8GB |
| RAM | 1GB DDR3 |
| General Configuration |
| Display | 4.0inch IPS 480*800 |
| touch screen | Multi-point touch capacitive screen |
| Form Factor | Bar type classical PDA,Industrial appearance |
| GPS | Supports GPS/QZSS/SBAS (WAAS/MSAS/EGNOS/GAGAN). Support Full AGPS |
| Bluetooth | v2.1+EDR / 3.0+HS / v4.0 Low Energy (LE) |
| WiFi | 2.4Ghz 802.11 b/g/n |
| RFID NFC | RFID NFC(Compatible 13.56MHz ISO 14443A/ ISO15693) |
| External Interface | USB HOST/RS232(Customized) |
| Protection class | IP65 |
| Drop resistance level | 1.5m |
| Camera Function | Camera | 8MP Camera |
| Video | Support still image and video capture |
| Keypad | Front /Side | 23 / 3key |
| Interface | Mini-USB connector | USB2.0 OTG |
| SIM card slot | 1 standard SIM slot apply GSM,GPRS, EDGE |
| 1 Micro SIM slot apply 3G |
| TF card slot | Yes |
| power jack | Yes |
| Audio Jack | Yes |
| Battery | Type | rechargeable Li-ion battery 4200mAh |
| Standby Time | 500hours |
| Calls Time | Up to 6hours |
| Charging Time | 4 hours |
| Physical Characteristics | Dimension | 166*74*16mm (Thickest 30mm) |
| Weight | >300g with battery (according config) |
| OPTIONS |
| Barcode Scanner | 1D scanner |
Symbol SE955 --1D laser barcode reader (Optional 1) |
| Honeywell N4313--1D laser barcode reader (Optional 2) |
| 1D/2D scanner | Newland EM3095--1D/2D barcode reader-hardware decoding (Optional 1) |
| Symbol SE4500SR--1D/2D barcode reader-software decoding (Optional
2) |
Our Services of barcode scanner PDA
As a listed company from china manufacturer for barcode scanners,
we support you:
- Completely Free SDK including source code and technical support.
- ODM/OEM and 6 kinds of customization services according to your needs.
- 13 months warranty for your devices and other parts. and 6 months for the batteries.
It'll cost 0.5% for each per year for extended warranty.
- Free maintenance of the devices and part of accessories replacement in the warranty. You'll have to pay the basic cost for them if out of warranty
period.
- Strong productivity gurantee your delivery time for your emergency.
1.As a hardware PDA producer, We also offer OEM/ODM design and manufacturing service for
hardware required for Data collector terminal PDA, including
| 1. Price ranges | Factory direct with competitive and wholesale price with different
demands |
| 2. Modules Options | Over 18 kinds of module functions are optional to meet your demands |
| 3. 3 Operation System | 3 OS can be optional: Win Mobile/CE and Android |
| 4. Colors Options | 4 kinds of colors to choose: yellow, green, grey and blue. |
| 5. Customizations | Support OEM/ODM services with LOGO or Mainboard for our customers
by Foxconn |
| 6. Wide Solutions | it supplies wide and various industrial solutions to make effective
enterprises. |
8 years' experience of R&D and OEM/ODM services for customers all over the world. More details As below
More customized services are provided to make your enterprises more
effective and efficient.
2.As for software integration , We not only support 18 kinds of multiple modules but also supply
3 compatible operating systems. Those Including
| 1.1D/2D barcode scanner | 5.Thermal Printer | 9. 433M | 13.Bluetooth /WiFi |
| 2.Fingerprint reader | 6.IC reader | 10.ZigBee | 14.GPS/GPRS |
| 3.LF/HF/UHF RFID reader | 7.PSAM | 11.IR Meter reading | 15.2G /3G /4G |
| 4.NFC RFID reade | 8.MSR reader | 12.Temperature Reader | 16.Camera/Video |
Company Information
Beijing Speedata Technology Co., Ltd (stock code: 832442 ), founded in 2008, is a provider of IoT
(Internet of Things)solutions and OEM/ODM manufacturer of wireless hardware terminal and software solution, focusing on such wireless network enabling technologies as 1D/2D
Barcode scanner, RFID , 433M, MSR, ZigBee, PSAM, IC card reader,
thermal printer,fingerprint reader----
Every Year, we have a lot of activities and promotions for hottest
barcode scanners during the Exhibition. Attention us to get a big
discount price. Thank you!
At the same time, we successfully cooperated with Foxconn by
OEM/ODM in Shenzhen.
This KT40 Series are assembled by Foxconn.
FAQ
Question 1: what's your barcode scanner MOQ?
Answer: the MOQ of speedata barcode scanner barcode scanner is 1
pcs.
Question 2: how long is the delivery time?
Answer: The delivery time of barcode scanner goods is different
from quantities:
If 1~100 pcs, It's about 5--10 working days;
If 100~500 pcs, it's about 10--20 working days;
If More than 500 pcs, It's about 20-30 working days.
Question 3: Would you like to supply 1 sample for testing?
Answer: Yes, Of course. We can provide 1 sample of barcode scanner
PDA for your testing.
Question 4: What's the total price for 1 sample?
Answer: As a manufacturer of barcode scanner terminal PDA.the more
you buy,the cheaper it'll be.
the sample price is a little bit higher than the common wholesale
price.excluding the freight fee.
Question 5: Are you a manufacturer of barcode scanner PDA?
Answer: Yes, we are a chinese listed company of R&D and
producing barcode scanner hardware and software. and also we
cooperate with Foxconn for OEM.
Question 6: what kind of services do you support?
Answer:1.We provide you Free SDK and technical support for your
barcode scanner.
2.we also provide ODM/OEM customization services according to your
needs.
3.We support 13months Warranty for your devices and other parts.
and 6 months for the batteries. Exend warranty,it costs 0.5% for
each per year.
Question 7: what's for payment term and delivery term ?
Answer: 1.It's generally 30%-100% TT in advance for all orders for
the payment term.
with supporting via bank card, Paypal or West Union.
2.FOB Shenzhen for Delivery term.
IF you need more information and details, Please Feel free to
contact us. Thanks for your attention.
