HF RFID Reader 13.56Mhz Industrial PDA With Passive Or Active Tags
Quick Details
1,Key feature: Basic functions as Smart phone.
2,Wireless functions: WIFI, BLUETOOTH, GPS( support full AGPS).
3,Wide range of purpose: Animal/container/tool identification; bus
card,ID card,attendance card; library, goods tracking, inspection,
medicine; vehicle management, asset management, high speed charge;
logistics&express, retail, FMCG; print railway ticket, print
bar/QR code; swipe passport/driving license/member card/magnetic
card.
4,Powerful productivity to make sure the delivery time.
5,Free SDK and 13 months warranty, technical support.
Specification
| KT45Q with options |
| Android OS |
| OS | Android 5.1 |
| Hardware |
| Core board | CPU | Quad-core 1.3Ghz
ARM® Cortex-A53 (LPDDR2 and LPDDR3) |
| WWLAN | FDD B1B3B7
TDD B38B39B40
WCDMA B1B2B5B8
EVDO BC0
GSM B2B3B5B8 |
| Flash ROM | 8GB |
| RAM | 1GB DDR3 |
| Motherboard |
| Display @ | 4.5inch IPS 480*854 |
| touch screen | Multi-point touch capacitive screen |
| Form Factor | Bar type classical PDA,Industrial appearance |
| GPS | Supports GPS/QZSS/SBAS (WAAS/MSAS/EGNOS/GAGAN). Support Full AGPS |
| DGPS (please check options) |
| Bluetooth | v2.1+EDR / 3.0+HS / v4.0 Low Energy (LE) |
| WiFi | 2.4Ghz 802.11 b/g/n |
| External Interface | USB HOST/RS232(Customized) |
| Protection class | IP65 |
| Drop resistance level | 1.5m |
| Camera Function | Camera | 8MP Camera |
| Video | Support still image and video capture |
| Sensor | G-sensor | YES |
| Keypad | Front | 17 |
| Side | 4 |
| Interface | Mini-USB connector | USB2.0 connection |
| SIM card slot | *2 |
| TF card slot | Yes |
| power jack | Yes |
| Audio Jack | Yes |
| Battery | Type | rechargeable Li-ion battery 4500mAh |
| Standby Time | 500hours |
| Calls Time | Up to 6hours |
| Charging Time | 4 hours |
| Physical Characteristics | Dimension | 175*76*27mm |
| Weight | >400g with battery (according config) |
| | | | | |
| OPTIONS |
| DGPS | ublox LEA-6T (with RTK) |
| MSR(Optional) | Compatible with one, two, three track(without PCI, EMV security
certification) |
| PSAM(Optional) | ISO7816 (SIM card interfance) |
| IC card reader(Optional) | ISO7816 ID-1 |
| Fingerprint reader | option 1 | TCS1G |
| option 2 | TCS1B |
| Printer | 2 inch Direct thermal line printing |
| Far Infrared Meter Reading (Optional) | IEC62056-21(IEC1107) communication protocol |
| 433Mhz module | Require customers to provide 433Mhz wireless modules or
specifications. |
| zigbee | Require customers to provide 433Mhz wireless modules or
specifications. |
| RFID Reader | option 1 | LF RFID(134.2khz, ISO11784/11785, FDX-B/HDX) |
| option 2 | LF RFID(125KHz) |
| option 3 | HF RFID(13.56MHz ISO 1443A/B ISO 15693) |
| option 4 | NFC(include 13.56MHz ISO 1443A/B ) |
| option 5 | UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) / ISO18000-6A,B
compatibility in direct mode----with AS3992 shipset |
| option 6 | UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) ----with R2000 shipset,
Long distance reader. |
| option 7 | UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) -with PR92000 shipset |
| Barcode scanner | option 1 | NEWLAND:EM1300(1D barcode reader) |
| option 2 | NEWLAND:EM3000(1D/2D barcode reader) |
| option 3 | Symbol:SE955(1D laser barcode reader) |
| option 4 | HoneyWell:N4313 (1D laser barcode reader) |
| option 5 | Symbol: SE4500(1D&2D barcode reader) |
| Printer Module Specifications |
| Printing method | Direct thermal line printing |
| Paper width | 57mm |
| Print width | 48mm |
| Resolution Ration | 8 dots/mm (384 dots/line ) |
| Life of printing head | 5,000,000 -15,000,000 character lines |
| Printing speed | 40-60mm/sec |
| Character size | 8*16dots , 12*24dots |
| Paper supplied | 57mm wide , 22mmø |
| Interface | Serial RS232C/TTL |
| Operating temperature | 0℃--50℃ |
| Storage temperature | -20℃ -- 60℃ |
| Operating humidty | 10%--80% |
| Storage humidty | 10%--90% |
| Fingerprint Module Specifications |
| TYPE1 | TCS1G |
| Touchchip Sensor | Interface | 8 bit parallel interface
20-pin flex connector |
| Power(typical) | 4.5-4.6V supply
20mA during capture |
| Touchchip Module | Interface Options | 5-soldier pads for USB only @ 5V
12-pin flex: USB,SPI,UART @ 3.3V (optional) |
| Power(typical) | 3.0V-3.6V
80mA(capture,match)
Standby(USB) :1350 uA
Standby(UART/SPI) : 1150uA
Wake-up time: <15 ms (Sleep to imaging) |
| Digital ID Hardware Engine | Biometric Companion Processor | - 1:1 match time ~50uS per template
- 1:100 match time <2s typ.
- On-board NVM storage for up to 100 templates
- More than 100,000 erase/write cycles
- More than 20 years data retention |
| Common Spec | Fingerprint Image | 12.8×18.0mm(256×360pixels)
508dpi,8-bit greyscale |
| Sensor Coating | gold coating,FIPS-201 Compliant (EIM) |
| Package Size | 23 mm x 35 mm x 4.1 mm |
| ESD | IEC 61000 - 4.2 level 4, +/- 15KV air, +/- 8IKV contact |
| Ingress Protection | IP 65 (water/dust protection) |
| Environmental | • Operating temp: -30 to +70 C
• Storage temp: -30 to + 125 C
• Humidity: 5% - 93% non-condensing
• ROHS, low halogen |
| TYPE2 | TCS1B |
| Touchchip Sensor | Interface | 8 bit parallel interface
20-pin flex connector |
| Power(typical) | 4.5-5.5 supply
20mA during capture |
| Touchchip Module | Interface Options | 5-soldier pads for USB only @ 5V
12-pin flex: USB,SPI,UART @ 3.3V (optional) |
| Power(typical) | 3.0V-3.6V
80mA(capture,match)
Standby(USB) :1350 uA
Standby(UART/SPI) : 1150uA
Wake-up time: <15 ms (Sleep to imaging) |
| Digital ID Hardware Engine | Biometric Companion Processor | - 1:1 match time ~50uS per template
- 1:100 match time <2s typ.
- On-board NVM storage for up to 100 templates
- More than 100,000 erase/write cycles
- More than 20 years data retention |
| Common Spec | Fingerprint Image | 12.8×18.0mm(256×360pixels)
508dpi,8-bit greyscale |
| Sensor Coating | SteelCoat(black coating) EIM-Lite |
| Package Size | 23 mm x 35 mm x 4.1 mm |
| ESD | IEC 61000 - 4.2 level 4, +/- 15KV air, +/- 8IKV contact |
| Ingress Protection | IP 65 (water/dust protection) |
| Environmental | • Operating temp: -30 to +70 C
• Storage temp: -30 to + 125 C
• Humidity: 5% - 93% non-condensing
• ROHS, low halogen |
| Certificate | STQC |
Service
- Completely Free SDK and technical support for you.
- ODM/OEM and 6 kinds of customization services according to your needs.
- 13months warranty for your devices and other parts. and 6 months for the batteries.
Extend warranty,it'll cost 0.5% for each per year.
- Free maintenance of the devices and part of accessories replacement in the warranty .if out of the warranty, you'll have to pay the basic cost for
them.
Company Information
Beijing Speedata Technology Co., Ltd (stock code: 832442 ), founded in 2008, is a provider of IoT
(Internet of Things) solutions and OEM/ODM manufacturer of wireless
hardware terminal and software solution, focusing on such wireless
network enabling technologies as 1D/2D Barcode scanner, RFID ,
433M, MSR, ZigBee, PSAM, and IC card reader...
We are headquartered in Beijing, with sales/R&D offices in
Shanghai, Shenzhen, Dalian, and Tianjin city of China, and two
manufacturing facilities, one in Beijing and one in Tianjin.
