    Wearable Smartphone Android Barcode Scanners Handheld PDA GPRS

    Ask Lasest Price
    Brand Name : Speedata
    Model Number : KT45Q-C8M-NL
    Certification : CCC,CQC,ISO9001,IP65,CE
    Payment Terms : T/T, Western Union, MoneyGram,PayPal
    Supply Ability : 5000pcs/months
    Delivery Time : 3-7 work days
    • Product Details
    • Company Profile

    Wearable Smartphone Android Barcode Scanners Handheld PDA GPRS

    Wearable Smartphone Android Barcode Scanners Handheld PDA GPRS

    Description of KT45Q

    1, Android 5.1 OS.

    2, Support 4G LTE.

    3, An open platform and flexible function configuration.

    4, Multiple interface:USB 2.0, SIM/TF card slot, power/audio jack, USB HOST/RS232(Customized).


    Paramaters of KT45Q
    Development Environment
    Operating SystemAndroid 5.1
    SDKSoftware Development Kit
    LanguageJava
    Fundamental Characteristics
    CPUQuad-core 1.3Ghz ARM® Cortex-A53 (LPDDR2 and LPDDR3)
    Memory1GB DDR3 RAM + 8GB Frash ROM
    StorageMicro SD/TF card max.32GB expansion
    Display4.5-inch IPS 480 * 854 Multi-point touch capacitive screen
    Communications
    4G WWLANFDD B1B3B7
    TDD B38B39B40
    WCDMA B1B2B5B8
    EVDO BC0
    GSM B2B3B5B8
    WiFi2.4Ghz 802.11 b/g/n
    G-SensorYes
    BluetoothV2.1+EDR / 3.0+HS / V4.0 Low Energy(LE)
    GPSSupports GPS/QZSS/SBAS (WAAS/MSAS/EGNOS/GAGAN). Support Full AGPS
    DGPS (please check options)
    Physical Characteristics
    Dimensions175 * 76 * 28mm
    WeightMore 400g (includes main battery)
    Expansion Slots1*PSAM, 2*SIM
    Batteryrechargeable li-ion battery 4500mAh 3.7V
    Or rechargeable li-ion battery 2250mAh 7.4V (if with printer)
    500hours standby time, Up to 6hours calling time, 4hours charging time
    Camera8MP Camera
    VideoSupport still image and video capture
    Audio3.5mm 4way plug
    KeypadFront 17keys, Side 4keys
    Interfaces1*MicroSD/TF, 1*Audio Jack, 1*Micro USB, 1*Power Jack
    USB Host (Optional), RS-232 interface (Optional)
    User Environment
    Operating Temp.-10 to 50℃
    Humidity10%RH - 90%RH (Non-condensing)
    Protection classIP65
    Drop resistance level1.5M
    Data Modules
    Barcode scanners (optional )
    1D Linear Scanner (Optional)
    1D scannerSymbol SE955 (Optional 1)
    Newland EM1300 (Optional 2)
    Honeywell N4313 (Optional 3)
    2D Imager Scanner (Optional)
    1D/2D scannerSymbol SE4500 (Optional 1)
    Newland EM3000 (Optional 2)
    RFID readers (optional)
    LF RFID reader134.2khz, ISO 11784/11785, FDX-B/HDX (Optional 1)
    125khz (Optional 2)
    HF RFID reader13.56MHz, ISO 14443A/B, ISO 15693
    NFC readerInclude 13.56MHz, ISO 1443A/B
    UHF RFID reader860-960MHZ ISO18000-6C (EPC Gen2) / ISO18000-6A,B compatibility in direct mode----with AS3992 chipset
    860-960MHZ ISO18000-6C (EPC Gen2) / ISO18000-6A,B compatibility in direct mode----with R2000 chipset, Long distance reader
    Biometric fingerprint Reader (optional )
    Fingerprint SensorCrossmatch TCSIG (meet FBI FIPS201 ) (Optional 1)
    Fingerprint SensorCrossmatch TCS1B (meet STQC ) (Optional 2)
    Fingerprint SensorUPEK TCSI (meet FBI's FIPS-201)
    Fingerprint SensorUPEK TCS2SS
    Other Modules (optional )
    DGPSUblox LEA-6T (with RTK)
    PSAMISO7816 (SIM card interface)
    MSRCompatible with one, two, three track(without PCI, EMV security certification)
    IC card readerISO7816 ID-1
    PrinterIntegrete 2inch Direct thermal line printing
    Far Infrared Meter ReadingIEC62056-21 (IEC1107) communication protocol
    433MhzRequire customers to provide 433Mhz wireless modules or specifications
    ZigbeeRequire customers to provide 433Mhz wireless modules or specifications


    Value for Clients


    Values


    For system integrator:


    Original manufacturer long term support
    Meet your high-end clients project demands
    Most cost-efficient/one stop solution
    ODM/OEM services

    For end user:


    Promote 70% inventory speed
    Save 45% processing cost
    Avoid 30% articles unused/waste/Stealing
    Keep big data push improving

    For partner:


    Semi-finished modules product available directly
    Share Market
    Save 80% R&D cost
    Save 70% new products arrival time

    OEM Service

    1. As a hardware PDA producer, We also offer OEM/ODM design and manufacturing service for hardware required for Data collector terminal PDA, including

    Brand & Logo

    Different colors

    Multiple modules integration

    Wide industrial and business solutions

    Competitive and diverse price ranges


    8 years' experience of R&D and OEM/ODM services for customers all over the world.

    1.Price ranges: Factory direct with competitive and wholesale price with different demands

    2. Modules Options:

    Over 18 kinds of module functions are optional to meet your demands

    3. Three Operation Systems:

    Three OS can be optional: Win Mobile/CE and Android

    4. Colors Options:

    Four kinds of colors to choose: yellow, green, grey and blue.

    5. Customization:

    Support OEM/ODM services with LOGO or Mainboard for our customers by Foxconn

    6. Wide Solutions:

    It supplies wide and various industrial solutions to make effective enterprises.


    2. As for software integration , We not only support 18 kinds of multiple modules but also supply 3 compatible operating systems. Those Including

    The most popular Android 4.4 and Windows CE or Mobile

    1D/2D barcode scanner

    LF/HF/UHF RFID as well as NFC RFID Function.

    Biometric fingerprint reader

    Thermal printer

    DGPS/ PSAM/ 433M/ IC Card/ MSR/ IR Meter Reading


    Company Information

    Beijing SPEEDATA handheld terminal adopt flexible configuration open platform, using Windows Mobile / Windows CE / Android operating system. The terminal integrated 1D/2D Barcode scanner, LF/HF/UHF RFID Reader, 8MP Camera ,GPS,WLAN,Bluetooth, 4G Communication function module; Provide customized service, provide best carrier for customers' data business, bring best experience for the users.

    Company "Speedata" brand products sell well both domestic and abroad .we have many sales outlets in domestic market ,clients contains: Hanting hotel,bright dairy, unilever, hainan mobile, Qinghua Tongfang, logistics etc ; Overseas customers in USA,,Mexico,Italy , Egypt,Ukraine and other countries.


    Applications

    We provide free SDK for corresponding functional PDA, like barcode demo, fingerprint demo, printer demo, RFID demo, IC card demo etc.


    We have a strong R&D team for not only hardware but also software, have developed the following solutions for our customers:

    Cold-chain logistics and transportation tracking

    meat product tracking

    Mobile police service

    Fixed-Assets management

    Tickets checking

    More industrial solutions of management systems as following:

    1. Logistics & Express
    2. Transportation
    3. Electric meter readings
    4. Network community management
    5. Storage & Distribution
    6. Petrochemical inspection
    7. Geomatics & Surveying
    8. Product tracking
    9. Health & pharmaceutical industry
    10. Mobile police service
    11. Tobacco Logistics
    12. Fixed-assets management
    13. Surveying and mapping
    14. Agriculture
    15. Water conservation
    16. Animal tracking & research
    17. Retail chain

    Why choose us

    Why choose us


    HistoryFounded in 2018
    Stock code832442
    ProductionTwo factories, own quality inspection department
    InternationalMore than 100countries
    CertificatesISO9001/CCC/CQC/CE/IP65
    After-Sale Service13 months warranty period
