WIN Mobile Handheld UHF RFID Reader Scanner with Long Range Smart
Modules
Quick Details of UHF reader:
1, 4.5inch high-definition IPS LCD capacitive touch screen to meet
your visual enjoyment
2, 5MP camera with high definition ,it's easy to collect all kinds
of image information
3, Support 1D/2D barcode scanning,LF/HF/UHF RFID/fingerprint
reading, terminal printer, MSR, PSAM function etc
4, Android Operation System, More Stable and Reliable,provide
complete SDK and technical support to make further app development
easily
5, Special structure and external cushion protection design, solid
and waterproof body shape
6, Matched with the machine seat charger, to ensure the charging
interface durable,it's more quicker and easier
7, IP65 Industrial Class, 1.5M drop protection
8, Multiple Functions optional: card reader, printer, fingerprint,
infrared reader, temperature, etc
Specifications of UHF reader:
| OS option |
| OS | option 1 | Windows mobile 6.1/6.5 |
| option 2 | WM CE 6 |
| option 3 | Android 4.0 |
| Hardware |
| Core board |
| CPU | TI3715 A8 1Ghz |
| WWLAN | option 1 | without modem |
| option 2 | Huawei MU609 Module: GSM band 850/900/1800/1900MHz, GPRS, EDGE UMTS
850/900/1900/ 2100MHz HSPA ) |
| Phone call &SMS function | NA. (Only supports Internet access.) |
| Memory | Flash ROM | 512MB |
| RAM | 512MB DDR |
| Extend Slot | Micro SD 32G (SDHC) |
| EMMC ROM | OPTION | 4GB ROM |
| Motherboard |
| Display | 4.5inch IPS 854*480 (Without Transflective screen) |
| touch screen | 4-wire resistive |
| Form Factor | Bar type classical PDA,Industrial appearance |
| GPS | UBLOX 6010 |
| Bluetooth | JORJIN WG7310 Bluetooth |
| WiFi | JORJIN WG7310 WiFi (802.11 b/g/n) |
| External Interface | USB HOST/RS232(Customized) |
| Protection class | IP65 |
| Drop resistance level | 1.5m |
| Camera Function | Camera | 5MP Camera |
| Video | Support still image and video capture |
| Keypad | Front | 17 |
| Side | 4 |
| Interface | Mini-USB connector | USB2.0 connection |
| SIM card slot | Yes |
| TF card slot | Yes |
| power jack | Yes |
| Audio Jack | Yes |
| Battery | Type | rechargeable Li-ion battery 4500mAh |
| Standby Time | 500hours |
| Calls Time | Up to 6hours |
| Charging Time | 4 hours |
| Physical Characteristics | Dimension | 175*76*27mm |
| Weight | >400g with battery (according config) |
| Extensions |
| PSAM(Optional) | ISO7816 (SIM card interfance) |
| MSR(Optional) | Compatible with one, two, three track. (without PCI, EMV security
certification.) |
| IC card reder(Optional) | ISO7816 ID-1 |
| Fingerprint reader | option 1 | UPEK TCS1 (meet the FBI’s FIPS-201) |
| option 2 | UPEK TCS2SS |
| Printer(Optional) | 2 inch Direct thermal line printing |
| Far Infrared Meter Reading (Optional) | IEC62056-21(IEC1107) communication protocol |
| zigbee(Optional) | 2.4Ghz |
| RFID | option 1 | LF RFID(134.2khz, ISO11784/11785, FDX-B/HDX) |
| option 2 | LF RFID(125KHz) |
| option 3 | HF RFID(13.56MHz ISO 1443A/B ISO 15693) |
| option 4 | NFC(include 13.56MHz ISO 1443A/B ) |
| option 5 | UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) / ISO18000-6A,B
compatibility in direct mode----with AS3992 shipset |
| option 6 | UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) with R2000 shipset |
Product Use of UHF reader:
1. Storage and logistics inventory.
2. Read staff cards for checking in.
3. Transportation,tobacco,inspection.
4. Vehicle management.
5. Charge for vehicles on highway.
6, Parking management on community or parking pot.
7. Data collector in many areas.
8. Cold-chain logistics and transportation tracking
9. Meat product tracking
10, Mobile police service
Advantages of UHF reader:
1. Experienced
More than 8 years experience in production(OEM/ODM included),
R&D and overseas sales, we have been a good manufacturer and
business partner.
2. High Quality Products
High protection grade: IP65 and 1.5M drop resistance
All of our products meet the CE standard.
Super Abilities of integration and productions
3. Satisfied Service
Before-Sale Service: quick response within ONE working day; patient
communication
On-Sale Service: delivery on time,quality and quantity assured
After-Sale Service: 13 months warranty period;
Besides, support complete SDK info and technology service during
your project.
4. Real Time Support
Speedata Support Team is at your fingertips and will help you
troubleshoot any issues with hardware or software, while answering
all your questions or concerns. Our own personal service technician
is assigned and readily available, so there is ZERO waiting time
for your absolute convenience.
