| SD100 Basic Parameters |
| OS | Android 8.1 |
| CPU | Octa-Core 2.0GHz |
| RAM | 4GB |
| ROM | 64GB |
| Expansion | Micro SD (TF) card slot up to 128GB |
| Keypad | 12 buttons |
| Notification | Sound/vibration/LED prompt |
| Audio | Front dual stereo speakers, Volume 90db±3db(test distance 10cm) |
| Dimentions | 254*176*17.4mm |
| Weight( with battery) | 800g |
| Camera |
| Camera | Rear camera 13MP AF+High brightness LED flash+Front Camera 5MP FF |
| Focus mode | Autofocus ; Fixed focus |
| Flash | Support single color LED Flash |
| Display |
| Display | 10.1 inch IPS high light screen |
| Resolution | 1200*1920 |
| Touch Panel | 5-point capacitive touch screen |
| Power |
| Battery | 9000mAh |
| Charging | PE fast charging, fully charging time< 4 hours |
| Interface | 2micro SIM cards, 1micro SD card slot up to 128GB, USB-Type C,
support fast charging, OTG,Support fast charging5V/9A 1.67,3.55mm
headphone jack,magnetic adsorption charging interface |
| Communication |
| Bluetooth | BT4.1 BLE |
| WLAN | WiFi 802.11 a/b/g/n 2.4G 5G |
| WWAN | FDD-LTE B1/B3/B5/B7/B8
TDD-LTE B38/B39/B40/B41
TDSCDMA B34/B39
WCDMA B1/B2/B5/B8
GSM B2/B3/B5/B8
CDMA1x/CDMA2000 BC0/BC1 |
| GPS | GPS+BD+GLONASS |
| Performance |
| Operation Temperature | -20℃ ~55℃ |
|
| Storage Temperature | -30℃ ~+70℃ |
| Humidity | 5%~95%(No condensation) |
| Sealing | IP65 |
| Drop Test | In the operating range, 6 sides can withstand the impact of 1.0
meters
drop to the concrete floor |
| ESD | ±15kV Air Discharge, ±8kV Contact Discharge |
| Certificate | CCC,CE |
| Extensibility |
| NFC | Support agreement:ISO14443A/B, ISO15693
reading distance: 0~5cm |
Code scanning
Support code system | CM60, Support code
system:EAN13, EAN8, UPCA, UPCE
Code 128, Code 39, Codabar, UCC/EAN128
RSS,ITF, ITF14, ITF6, ISSN, ISBN
Standard 25, Matrix 25,Industrial 25
Plessey, MSI Plessey, Code 11, Code 93
PDF417, QR Code, DataMatrix, AZTEC
Hanxin Code, Maxicode, Micro QR
Micro PDF417, Composite |
| RFID (UHF)(optional) | Protocol standard:ISO18000-6C
Work frequency : China(920-925MHz)
North America (902-928MHz)
European frequency(865-867MHz)
Antenna parameters:ceramic
antenna(1.5dBi) ,Power:working
voltage:4V-5V,Radio frequency input:5dBM
to 30dBM(1W),1dBM adjustable standby
power consumption about 0.25W, the larger
is 5W (typical 4W),Scope of
identification:indoors 3 meters or more
outdoors 1.5 meters or more, Label
speed >200/sec |
| Explosion-proof(optional) | Sign of explosion-proof:Ex ib IIC T4 Gb,
Certificate number:CCRI 19.2205X |
| PSAM | Support |
| Sensor | Geomagnetism, acceleration, optical distance |
| Optional Accessories | |
EM100ID
Second generation ID card back clip | Read distance: 0~3cm
Work frequency:meet the standard about
ISO14443 Type B 13.56MHz
Main features:2 or 3 belt ID card ,compatible
with four kinds of chip ID cards,support for
foreigners to read permanent resident
identity cards,Supporting the reading of
permanent resident identity cards in
Hong Kong, Macao and Taiwan |
DC100
Single charging base | input: 9V 2A
2 USB A-type ports |
