3.5 inch Wireless IP65 Rugged PDA Thermal Printer for Printing Ticket Invoice

Product Categories

Beijing Speedata Technology Co., Ltd

Contact Now

3.5 inch Wireless IP65 Rugged PDA Thermal Printer for Printing Ticket Invoice

Ask Lasest Price
Brand Name :	Speedata
Model Number :	TT35-B2-NL-E27
Certification :	IP65 , CE
Payment Terms :	Western Union, MoneyGram, PayPal
Supply Ability :	3000pcs / month
Delivery Time :	5-7days after receiving payment

Add to Cart

Product Details
Company Profile

3.5 inch Wireless IP65 Rugged PDA Thermal Printer for Printing Ticket Invoice

3.5 inch Wireless IP65 Rugged PDA Thermal Printer for Printing Ticket Invoice

OEM orders are accepted

SDK provided
Technical support by professional engineer
Maintain repair
13months warranty
After-sales service

Speedata TT35 Series

1. 3.5 inch daylight visible screen
2. Superior scalability: Maximum can support 4 extensions.
3. customization: Customers can customize their own modules.
4. Protection class: IP65.
5. Android/Win Mobile/Win CE operationg system (optional)

Data Sheet

Printer Module Specifications
Printing method		Direct thermal line printing
Paper width		57mm
Print width		48mm
Resolution Ration		8 dots/mm (384 dots/line )
Life of printing head		6,000,000 character lines
Printing speed		20mm/sec (when the utilization is 25%)
Character size		816dots , 1224dots
Paper supplied		57mm wide , 30mmø
Interface		Serial RS232C/TTL
Input power		DC 5--8.5V ,15W
Operating temperature		5℃--50℃
Storage temperature		-20℃--60℃
Operating humidty		10%--80%
Storage humidty		10%--90%

Data Sheet

Display			3.5inch TFT LCD (Transflective screen VGA )
touch screen			4-wire resistive
Form Factor			Bar type classical Pocket PC,Industrial appearance
GPS			UBLOX module
Bluetooth			JORJIN WG7310 Bluetooth
WiFi			JORJIN WG7310 WiFi (802.11 b/g/n)
RFID Reader		option1	LF RFID(134.2khz, ISO11784/11785, FDX-B/HDX)
		option 2	LF RFID(125KHz)
		option 3	HF RFID(13.56MHz ISO 14443A/B)
		option 4	HF RFID(13.56MHz ISO 1443A/B ISO 15693)
		option 5	NFC Reader (only android OS)
		option 6	UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) / ISO18000-6A,B compatibility in direct mode----with AS3992 shipset
		option 7	UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) / ISO18000-6A,B compatibility in direct modee----with inpinj R2000 shipset
Barcode scanner		option 1	NEWLAND:EM1300(1D Infrared barcode reader)
		option 2	NEWLAND:EM3000(1D/2D barcode reader)
		option3	symbol:SE955(1D laser barcode reader)
		option4	HoneyWell:N4313 (1D laser barcode reader)
		option 5	Honeywell:5100(1D/2D barcode reader)
		option 6	symbol se4500(1D&2D bar code reader)
External Interface			USB HOST/RS232(Customized)
Protection class			IP 65
Drop resistance level			1.5m
Camera Function	Camera		5MP AF
	Video		Support still image and video capture
Keypad	Front		30keys
	Side		4keys
