ISO9001 IP65 Certification Of Android Phone with Fingerprint Reader Terminal Handheld Android 5.1

Ask Lasest Price
Brand Name :	Speedata
Model Number :	KT45Q-C8M-TCS1G
Certification :	ISO9001,CCC,CQC,IP65,CE
Payment Terms :	T/T
Supply Ability :	10000 pcs per month
Delivery Time :	3-7 days after payment

Add to Cart

Product Details
Company Profile

ISO9001 IP65 Certification Of Android Phone with Fingerprint Reader Terminal Handheld Android 5.1

ISO9001 IP65 Certification Of Android Phone with Fingerprint Reader Terminal Handheld Android 5.1

Specification

Android OS
OS		Android 5.1
Hardware
Core board	CPU	Quad-core 1.3Ghz ARM® Cortex-A53 (LPDDR2 and LPDDR3)
	WWLAN	FDD B1B3B7 TDD B38B39B40 WCDMA B1B2B5B8 EVDO BC0 GSM B2B3B5B8
	Flash ROM	8GB
	RAM	1GB DDR3
Motherboard
Display @		4.5inch IPS 480*854
touch screen		Multi-point touch capacitive screen
Form Factor		Bar type classical PDA,Industrial appearance
GPS		Supports GPS/QZSS/SBAS (WAAS/MSAS/EGNOS/GAGAN). Support Full AGPS
		DGPS (please check options)
Bluetooth		v2.1+EDR / 3.0+HS / v4.0 Low Energy (LE)
WiFi		2.4Ghz 802.11 b/g/n
External Interface		USB HOST/RS232(Customized)
Protection class		IP65
Drop resistance level		1.5m
Camera Function	Camera	8MP Camera
	Video	Support still image and video capture
Sensor	G-sensor	YES
Keypad	Front	17
	Side	4
Interface	Mini-USB connector	USB2.0 connection
	SIM card slot	*2
	TF card slot	Yes
	power jack	Yes
	Audio Jack	Yes
Battery	Type	rechargeable Li-ion battery 4500mAh
	Standby Time	500hours
	Calls Time	Up to 6hours
	Charging Time	4 hours
Physical Characteristics	Dimension	1757627mm
	Weight	>400g with battery (according config)

OPTIONS
DGPS		ublox LEA-6T (with RTK)
MSR(Optional)		Compatible with one, two, three track(without PCI, EMV security certification)
PSAM(Optional)		ISO7816 (SIM card interfance)
IC card reader(Optional)		ISO7816 ID-1
Fingerprint reader	option 1	TCS1G
	option 2	TCS1B
Printer		2 inch Direct thermal line printing

Fingerprint Module Specifications
TYPE1		TCS1G
Touchchip Sensor	Interface	8 bit parallel interface 20-pin flex connector
	Power(typical)	4.5-4.6V supply 20mA during capture
Touchchip Module	Interface Options	5-soldier pads for USB only @ 5V 12-pin flex: USB,SPI,UART @ 3.3V (optional)
	Power(typical)	3.0V-3.6V 80mA(capture,match) Standby(USB) :1350 uA Standby(UART/SPI) : 1150uA Wake-up time: <15 ms (Sleep to imaging)
Digital ID Hardware Engine	Biometric Companion Processor	- 1:1 match time ~50uS per template - 1:100 match time <2s typ. - On-board NVM storage for up to 100 templates - More than 100,000 erase/write cycles - More than 20 years data retention
Common Spec	Fingerprint Image	12.8×18.0mm(256×360pixels) 508dpi,8-bit greyscale
	Sensor Coating	gold coating,FBI FIPS-201 Compliant (EIM)
	Package Size	23 mm x 35 mm x 4.1 mm
	ESD	IEC 61000 - 4.2 level 4, +/- 15KV air, +/- 8IKV contact
	Ingress Protection	IP 65 (water/dust protection)
	Environmental	• Operating temp: -30 to +70 C • Storage temp: -30 to + 125 C • Humidity: 5% - 93% non-condensing • ROHS, low halogen

Applications

1, Exhibition entrance checking

2, Staff enrollment and comparing

3, Goverment tax revenue

4, Mobile police service

5, Serveying and mapping

Advantages

Completely Free SDK

Technical support for you

ODM/OEM according to your needs

6 kinds of customization services

13months warranty for your devices and other parts, and 6 months for the batteries

Extend warranty,it'll cost 0.5% for each per year

Free maintenance of the devices and part of accessories replacement in the warranty .If out of the warranty, you'll have to pay the basic cost for them.

Various payment way including Paypal, western union, TT, etc.
