Stable Portable Biometric Fingerprint Scanner For Mobile With 4500mah 3.7v Battery

Product Categories

Beijing Speedata Technology Co., Ltd

Contact Now

Name: Stable Portable Biometric Fingerprint Scanner For Mobile With 4500mah 37v Battery
Brand: Speedata
Price: 1 USD

Ask Lasest Price
Brand Name :	Speedata
Model Number :	TT35
Certification :	ISO9001 FCC ROHS IP65 1.5M Drop assistance
Payment Terms :	Western Union, T/T, L/C
Supply Ability :	10000 pic / month
Delivery Time :	4-10days

Add to Cart

Stable Portable Biometric Fingerprint Scanner For Mobile With 4500mah 3.7v Battery

Parameters of TT35 android fingerprint reader :

Development Environment
Operating System	Windows Mobile 6.1/6.5 (Optional 1)
	Windows CE 6.0 (Optional 2)
	Android 4.0.3
SDK	Software Development Kit
Language	C#, java
Tool	Microsoft Visual Studio 2005
Fundamental characteristics
CPU	TI AM3715 A8 1Ghz
Memory	512MB DDR RAM + 512MB Frash ROM
Storage	Micro SD/TF card max.32GB expansion
Display	3.5-inch TFT LCD (Transflective screen VGA 640*480)
Display	4-wire resistive touch screen
Communications
WWLAN	Without modem (No 3G/GPSR Communication module) (Optional 1)
WWLAN	Huawei MU609 Module: GSM band 850/900/1800/1900MHz, GPRS, EDGE UMTS 850/900/1900/ 2100MHz HSPA ) (Optional 2)
WiFi	JORJIN WG7310 WiFi (802.11 b/g/n)
Bluetooth	JORJIN WG7310 Bluetooth
GPS	UBLOX 6010
Physical Characteristics
Dimensions	1828236mm
Weight	more than 400g with battery (according config)
Expansion Slots	2PSAM, 1SIM
Battery	rechargeable li-ion battery 4500mAh 3.7V
	Or rechargeable li-ion battery 2250mAh 7.4V (if with printer)
	500-hours standby time, Up to 6 -hours calling time, 4-hours charging time
Camera	5MP Camera
Video	Support still image and video capture
Audio	3.5mm 4way plug
Keypad	Front 30keys, Side 4keys
Interfaces	1MicroSD/TF, 1Audio Jack, 1Micro USB, 1Power Jack
Interfaces	USB Host/RS232 interface (Customized)
User Environment
Operating Temp.	-10 to 50℃
Humidity	10%RH - 90%RH (Non-condensing)
Protection class	IP65
Drop resistance level	1.5M

Multiple modules of TT35 android fingerprint reader :

Barcode scanners (optional )
1D Linear Scanner (Optional)
1D scanner	Symbol SE955 (Optional 1)
	NEWLAND EM1300 (Optional 2)
	HoneyWell N4313 (Optional 3)
2D Imager Scanner (Optional)
1D/2D scanner	NEWLAND EM3000-hardware decoding (Optional 1)
1D/2D scanner	Symbol SE4500-software decoding (Optional 2)
RFID readers
LF RFID reader	(134.2khz, ISO11784/11785, FDX-B/HDX) (Optional 1)
LF RFID reader	(125KHz) (Optional 2)
HF RFID reader	(13.56MHz ISO 14443A/B ISO 15693)
NFC reader	(include 13.56MHz ISO 14443A ISO 15693)
UHF RFID reader	UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) / ISO18000-6A,B compatibility in direct mode----with AS3992 shipset -- reading distance up to 3m
Biometric fingerprint (optional )
Fingerprint	SM-621B (optical fingerprint) (Optional 1)
Other Modules (optional )
DGPS	Ublox LEA-6T (with RTK)
PSAM	ISO7816 (SIM card interfance)
MSR	Compatible with one, two, three track. (without PCI, EMV security certification)
IC card reader	ISO7816 ID-1
Printer	Integrate 2inch Direct thermal line printing
Far Infrared Meter Reading	IEC62056-21 (IEC1107) communication protocol
433Mhz	Require customers to provide 433Mhz wireless modules or specifications
Zigbee	Require customers to provide 433Mhz wireless modules or specifications

Specifications of TT35 android fingerprint reader :

3.5inch high-definition IPS LCD capacitive touch screen,sunlight visible
30 Strong and stable keys buttons
Support 1D/2D barcode scanning,LF/HF/UHF RFID/fingerprint reading, terminal printer, MSR, PSAM function etc.
Built-in Ublox/beidou double GPS modules, more accurate positioning
Reserved identity recognition, fingerprint identification, infrared measuring temperature, etc.,
strong and wide extensibility
IP65 Industrial Class, 1.5M drop protection
Mutiple modules optional for your customization

Pictures of TT35 android fingerprint reader :

Stable Portable Biometric Fingerprint Scanner For Mobile With 4500mah 3.7v Battery
