Prducts Features:
- Especailly Design for Retail Management in Reading Clothing Tags
- 2GB RAM, 16GB ROM Memory Capacity
- Android 8.1 Operation System, Quad-Core 2.0GHz CPU
- Micro SD(TF) Card Slot Up to 128GB
- UHF RFID Reader, ISO14443-A/B, ISO15693
- Tiny and Light Handheld Terminal, portable to carry.
- 30° Convenient Scanning Angle and 4 Scanning Buttons for Quick
Operation
- OEM by Foxconn, Ensure the Good Quality and Seasonable Lead Time
- IP675Industrial Class-Waterproof, Dustproof, Shockproof
- Pasted the Certificates like CE/FCC/CCC/NCC/IP65, and 1.5M Drop
Test
|
Specifications
| SD55UHF Basic Parameters |
| OS | Android 8.1 |
| CPU | Quad-Core 2.0GHz |
| RAM | 2GB |
| ROM | 16GB |
| Expansion | 2Nano SIM cards,1micro SD card slot up to 128GB,USB-Type C, support
fast charging, OTG,Support fast charging5V/9A 1.67,charging and
bottom USB connector |
| Keypad | 2 audio buttons+2 function buttons(One on the left and one on the
right)+ 1 power button |
| Notification | Sound/vibration/LED prompt |
| Audio | 1609 Dual speakers,waterproof design, Dual silicon mic noise
reduction |
| Dimentions | 150mm*72.5mm*16.5mm |
| Weight( with battery) | 400g |
| Camera |
| Camera | Rear Camera 13MP AF(16MP PDAF option);Front Camera 5MP FF |
| Focus mode | Autofocus ; Front focus |
| Flash | Support single color LED Flash |
| Display |
| Display | 5.5 inches,IPS high light screen |
| Resolution | 720*1440 |
| Touch Panel | 5-point capacitive touch screen |
| Power |
| Battery | Large-capacity Li-ion battery 5800mAh |
| Charging | PE fast charging, fully charged time< 4 hours |
| Interface | support USB-TypeC, support fast charge, support OTG |
| Communication |
| Bluetooth | BT4.0 BLE |
| WIFI | IEEE 802.11 a/b/g/n 2.4G 5G |
| WWAN | FDD-LTE B1/B3/B5/B7 or B1/B4/B8/B13
TDD-LTE B38/B39//B40/B41
TDSCDMA B34/B39
WCDMA B1/B2/B5/B8
GSM B2/B3/B5/B8
CDMA1x/CDMA2000 BC0/BC1 |
| GPS | GPS,GLONASS,BeiDou |
| Performance |
| Operation Temperature | -20℃ ~+55℃ |
|
| Storage Temperature | -30℃ ~+70℃ |
| Humidity | 5%~95%(No condensation) |
| Sealing | IP67 |
| Drop Test | In the operating range, 6 sides can withstand the impact of 1.5
meters
drop to the concrete floor |
| Tumble Test | 6 contact surfaces rolling for 1000 times/ 0.5M |
| ESD | ±15kV Air Discharge, ±8kV Contact Discharge |
| Certificate | CCC,CE,ROHS,FCC |
| Extensibility |
| NFC RFID Reader | NFC (PN548) Support NFC Reader/writer, ISO14443-A/B/F, ISO18092,
FeliCa, MIFARE, ISO15693 |
| Barcode Scanner | 1D/2D: Honeywell N6603 or Speedata SD5670 |
| UHF RFID Reader | Impinj R2000 860-960MHz ISO18000-6C (EPC Gen2)
Reading distance Max 5m |
| PSAM | Support |
| Sensor | geomagnetism, acceleration, light perception distance,
berometer(optional), gyroscope (optional)
|
Products Details
Speedata Services
As a listed company from china manufacturer, we support you:
Completely Free SDK and technical support for you.
ODM/OEM customization services according to your needs.
13 months warranty for your devices and other parts. and 6 months
for the batteries. Exend warranty,it'll cost 0.5% for each per
year.
Free maintenance of the devices and part of accessories replacement
in the warranty .if out of the warranty, you'll have to pay the
basic cost for them.
FAQ
Question 1: What's your MOQ?
The MOQ of barcode scanner handheld PDA is 1 piece.
Question 2: How long is the delivery time?
The delivery time of barcode scanner goods is different from
quantities:
If 1~100 pcs, It's about 5--10 working days;
If 100~500 pcs, it's about 10--20 working days;
If More than 500 pcs, It's about 20-30 working days.
Question 3: Would you like to supply 1 sample for testing?
Yes, Of course. We can provide 1 sample Terminal PDA for your
testing.
Question 4: What's the total price for 1 sample?
As a manufacturer of barcode scanner terminal PDA,the more you buy,
the cheaper it'll be.
The sample price is a little bit higher than the common wholesale
price excluding the freight fee.
Question 5: Are you a manufacturer of Handheld PDA?
Yes, we are a R&D orientation China Listed Company, mainly
producing industrial PDA Terminal Hardware and as a software
solutions supplier with over 8 years' OEM/ODM experience. We are
also cooperating with Foxconn Factory.
Question 6: What kind of services do you support ?
We provide you Free SDK and Technical Support for your Barcode
Scanner.
We also provide ODM/OEM Customization Services based to your
demands.
We support 13 months Warranty for all the device and 6 months for
the batteries. Exend warranty, it costs 10% at the first year, and
15% for the second year.
Question 7: What's for payment term and delivery term ?
It's generally 30%-100% TT in advance for all orders. Meanwhile,
Paypal or West Union is acceptable.
FOB Shenzhen as Trade Term.
Question 8: Who are your customers?
Our products have been sold to worldwide,especially market in
South/North America, Europe, Asia, Africa Mid-east, etc.
The market share is increasing quickly every year and we get more
and more positive feedbacks from our customers.
