Laser Android Barcode Scanner , 4 Wire Resistive Touch Wireless
Thermal Printer
TT35is a rare product to have 3 different frequency range of LF
RFID, HF RFID, UHF RFID at the same time on the market, especailly
for a longrange UHF reader function. Also with 1D/2D stable barcode
scanning , 2.4G zigbee RFID reader with ultralongrange as well as
NFC reader function.we can use different scan module according to
your demands.
Specifications of TT35 best all in one PDA terminal printer
| Development Environment |
| Operating System | Windows Mobile 6.1/6.5 (Optional 1) |
| Windows CE 6.0 (Optional 2) |
| Android 4.0.3 |
| SDK | Software Development Kit |
| Language | C#, java |
| Tool | Microsoft Visual Studio 2005 |
| |
| Fundamental characteristics |
| CPU | TI AM3715 A8 1Ghz |
| Memory | 512MB DDR RAM + 512MB Frash ROM |
| Storage | Micro SD/TF card max.32GB expansion |
| Display | 3.5-inch TFT LCD (Transflective screen VGA 640*480) |
| 4-wire resistive touch screen |
| |
| Communications |
| WWLAN | Without modem (No 3G/GPSR Communication module) (Optional 1) |
Huawei MU609 Module: GSM band 850/900/1800/1900MHz, GPRS, EDGE UMTS 850/900/1900/ 2100MHz HSPA ) (Optional 2) |
| WiFi | JORJIN WG7310 WiFi (802.11 b/g/n) |
| Bluetooth | JORJIN WG7310 Bluetooth |
| GPS | UBLOX 6010 |
| |
| Physical Characteristics |
| Dimensions | 182*82*36mm |
| Weight | ≧400g with battery (according config) |
| Expansion Slots | 2*PSAM, 1*SIM |
| Battery | rechargeable li-ion battery 4500mAh 3.7V |
| Or rechargeable li-ion battery 2250mAh 7.4V (if with printer) |
| 500-hours standby time, Up to 6-hours calling time, 4-hours
charging time |
| Camera | 5MP Camera |
| Video | Support still image and video capture |
| Audio | 3.5mm 4way plug |
| Keypad | Front 30keys, Side 4keys |
| Interfaces | 1*MicroSD/TF, 1*Audio Jack, 1*Micro USB, 1*Power Jack |
| USB Host/RS232 interface (Customized) |
| |
| User Environment |
| Operating Temp. | -10 to 50℃ |
| Humidity | 10%RH - 90%RH (Non-condensing) |
| Protection class | IP65 |
| Drop resistance level | 1.5M |
Multiple modular options of TT35 best all in one PDA terminal printer
| Data Modules |
| Barcode scanners (optional ) |
| 1D Linear Scanner (Optional) |
| 1D scanner | Symbol SE955 (Optional 1) |
| NEWLAND EM1300 (Optional 2) |
| HoneyWell N4313 (Optional 3) |
| 2D Imager Scanner (Optional) |
| 1D/2D scanner | NEWLAND EM3000-hardware decoding (Optional 1) |
| Symbol SE4500-software decoding (Optional 2) |
| |
| RFID readers |
| LF RFID reader | (134.2khz, ISO11784/11785, FDX-B/HDX) (Optional 1) |
| (125KHz) (Optional 2) |
| HF RFID reader | (13.56MHz ISO 14443A/B ISO 15693) |
| NFC reader | (include 13.56MHz ISO 14443A ISO 15693) |
| UHF RFID reader | UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) / ISO18000-6A,B compatibility in direct mode ----with AS3992 shipset -- reading distance up to 3m |
| |
| Biometric fingerprint (optional ) |
| Fingerprint | SM-621B (optical fingerprint) (Optional 1) |
| |
| Other Modules (optional ) |
| DGPS | Ublox LEA-6T (with RTK) |
| PSAM | ISO7816 (SIM card interfance) |
| MSR | Compatible with one, two, three track. (without PCI, EMV security certification) |
| IC card reader | ISO7816 ID-1 |
| Printer | Integrate 2inch Direct thermal line printing |
| Far Infrared Meter Reading | IEC62056-21 (IEC1107) communication protocol |
| 433Mhz | Require customers to provide 433Mhz wireless modules or
specifications |
| Zigbee | Require customers to provide 433Mhz wireless modules or
specifications |
Advantages of TT35 best all in one PDA terminal printer
1.Universal product, Support extending corresponding module
according to customers'demands
2.Both ultra-sensitive resistive screen, durable and suitable for
complex industrial environments.
3.3 Operation Systems optional: Android, Mobile CE/Mobile
4.Both ultra sensitive resistive screen and rugged design with
durable and suitable for complex industrial environments.
Speedata best laser qr android barcode scanner PDA terminal printer
price from china manufacture
