Symbol Laser Barcode Scanner Handheld PDA Devices with Touch Screen
1GB CPU
Quick Details of barcode scanner:
1, Special structure and external cushion protection design, solid
and waterproof body shape
2, IP65 Industrial Class, 1.5M drop protection
3, Multiple Functions optional: card reader, printer, fingerprint,
infrared reader, temperature, etc
4, An open platform and flexible function configuration.
5, High quality hardware material and experienced software
engineers.
Specifications of barcode scanner:
| OS option |
| OS | option 1 | Windows mobile 6.1/6.5 |
| option 2 | WM CE 6 |
| option 3 | Android 4.0 |
| Hardware |
| Core board |
| CPU | TI3715 A8 1Ghz |
| WWLAN | option 1 | without modem |
| option 2 | Huawei MU609 Module: GSM band 850/900/1800/1900MHz, GPRS, EDGE UMTS
850/900/1900/ 2100MHz HSPA ) |
| Phone call &SMS function | NA. (Only supports Internet access.) |
| Memory | Flash ROM | 512MB |
| RAM | 512MB DDR |
| Extend Slot | Micro SD 32G (SDHC) |
| EMMC ROM | OPTION | 4GB ROM |
| Motherboard |
| Display | 4.5inch IPS 854*480 (Without Transflective screen) |
| touch screen | 4-wire resistive |
| Form Factor | Bar type classical PDA,Industrial appearance |
| GPS | UBLOX 6010 |
| Bluetooth | JORJIN WG7310 Bluetooth |
| WiFi | JORJIN WG7310 WiFi (802.11 b/g/n) |
| External Interface | USB HOST/RS232(Customized) |
| Protection class | IP65 |
| Drop resistance level | 1.5m |
| Camera Function | Camera | 5MP Camera |
| Video | Support still image and video capture |
| Keypad | Front | 17 |
| Side | 4 |
| Interface | Mini-USB connector | USB2.0 connection |
| SIM card slot | Yes |
| TF card slot | Yes |
| power jack | Yes |
| Audio Jack | Yes |
| Battery | Type | rechargeable Li-ion battery 4500mAh |
| Standby Time | 500hours |
| Calls Time | Up to 6hours |
| Charging Time | 4 hours |
| Physical Characteristics | Dimension | 175*76*27mm |
| Weight | >400g with battery (according config) |
| Extensions |
| PSAM(Optional) | ISO7816 (SIM card interfance) |
| MSR(Optional) | Compatible with one, two, three track. (without PCI, EMV security
certification.) |
| IC card reder(Optional) | ISO7816 ID-1 |
| Fingerprint reader | option 1 | UPEK TCS1 (meet the FBI’s FIPS-201) |
| option 2 | UPEK TCS2SS |
| Printer(Optional) | 2 inch Direct thermal line printing |
| Far Infrared Meter Reading (Optional) | IEC62056-21(IEC1107) communication protocol |
| zigbee(Optional) | 2.4Ghz |
| RFID | option 1 | LF RFID(134.2khz, ISO11784/11785, FDX-B/HDX) |
| option 2 | LF RFID(125KHz) |
| option 3 | HF RFID(13.56MHz ISO 1443A/B ISO 15693) |
| option 4 | NFC(include 13.56MHz ISO 1443A/B ) |
| option 5 | UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) / ISO18000-6A,B
compatibility in direct mode----with AS3992 shipset |
| option 6 | UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) with R2000 shipset |
| barcode scanner | option 1 | NEWLAND:EM1300(1D barcode reader) |
| option 2 | NEWLAND:EM3000(1D/2D barcode reader) |
| option 3 | Symbol:SE955(1D laser barcode reader) |
| option 4 | HoneyWell:N4313 (1D laser barcode reader) |
| option 5 | Symbol: SE4500(1D&2D barcode reader) |
Product Use of barcode scanner:
1. R & D technology support
2. Strong customized capabilities
Speedata serves wide industries and fields,
we pay more attention to design personalized software and hardware
products
we supply core board customization, sensors and module development
to combine with platform
Advantages of barcode scanner:
As for software integration , We not only support 18 kinds of multiple modules but also supply
3 compatible operating systems. Those Including
1. 1D/2D barcode scanner
2. Thermal Printer
3. 433M
4. Bluetooth /WiFi/GPS
5. Fingerprint Scanner
6. IC card reader
7. ZigBee
8. GPRS/WWLAN
9. LF/HF/NFC/UHF RFID reader
10. PSAM
11. IR Meter reading
12. MSR reader
13. Temperature Reader
14. Camera/Video
