Specifications
| SD60 Basic Parameters |
| OS | Android 8.1 |
| CPU | Octa-Core 2.0GHz |
| RAM | 2GB/4GB |
| ROM | 16GB/64GB |
| Expansion | Micro SD (TF) card slot up to 128GB |
| Keypad | 5 side buttons: 2 volume buttons,2 function buttons(1 left and
right),1 power button |
| Notification | Sound/vibration/LED prompt |
| Audio | Built-in speaker, Dual silicon mic noise reduction |
| Dimentions | 160*80*15.8mm |
| Weight( with battery) | 300g |
| Camera |
| Camera | Rear camera 13MP AF+High brightness LED flash+Front Camera 5MP FF |
| Focus mode | Autofocus ; Fixed focus |
| Flash | Support single color LED Flash |
| Display |
| Display | 6.0'' Full Screen |
| Resolution | 2160*1080 |
| Touch Panel | 5-point capacitive touch screen |
| Power |
| Battery | Large-capacity Removable Li-ion Battery 6000mAh |
| Charging | PE fast charging, fully charging time< 4 hours |
| Interface | support USB-TypeC, support fast charging, support OTG |
| Communication |
| Bluetooth | BT4.1 BLE |
| WLAN | WiFi iEEE 802.11 a/b/g/n 2.4G 5G Dual Frequency |
| WWAN | FDD-LTE B1/B3/B5/B7/B8
TDD-LTE B38/B39/B40/B41
TDSCDMA B34/B39
WCDMA B1/B2/B5/B8
GSM B2/B3/B5/B8
CDMA1x/CDMA2000 BC0/BC1 |
| GPS | GPS+BD+GLONASS |
| Performance |
| Operation Temperature | -20℃ ~+55℃ |
|
| Storage Temperature | -30℃ ~+70℃ |
| Humidity | 5%~95%(No condensation) |
| Sealing | IP65 |
| Drop Test | In the operating range, 6 sides can withstand the impact of 1.2
meters
drop to the concrete floor |
| Tumble Test | 6 contact surfaces rolling for 1000 times/ 0.5M |
| ESD | ±15kV Air Discharge, ±8kV Contact Discharge |
| Certificate | CCC,SRRC,CTA,CE,ROHS,FCC,BIS |
| Extensibility |
| NFC | Support agreement:ISO14443A/B, ISO15693
reading distance: 0~5cm |
Code Scanning
Support Code System | CM60, Support code system:EAN13
EAN8, UPCA, UPCE, Code 128, Code 39
Codabar, UCC/EAN128, RSS,ITF, ITF14, ITF6
ISSN, ISBN, Standard 25, Matrix 25
Industrial 25,Plessey, MSI Plessey, Code 11
Code 93, PDF417, QR Code, DataMatrix
AZTEC, Hanxin Code, Maxicode, Micro QR
Micro PDF417, Composite |
| PSAM | Support |
| Sensor | Geomagnetism, acceleration, optical distance |
| Explosion Proof (optional) | Sign of explosion-proof:Ex ib IIC T4 GB
Certificate number:CCRI 19.2161 |
Speedata Services
As a listed company from china manufacturer, we support you:
Completely Free SDK and technical support for you.
ODM/OEM customization services according to your needs.
13 months warranty for your devices and other parts. and 6 months
for the batteries. Exend warranty,it'll cost 0.5% for each per
year.
Free maintenance of the devices and part of accessories replacement
in the warranty .if out of the warranty, you'll have to pay the
basic cost for them.
FAQ
Question 1: What's your MOQ?
The MOQ of barcode scanner handheld PDA is 1 piece.
Question 2: How long is the delivery time?
The delivery time of barcode scanner goods is different from
quantities:
If 1~100 pcs, It's about 5--10 working days;
If 100~500 pcs, it's about 10--20 working days;
If More than 500 pcs, It's about 20-30 working days.
Question 3: Would you like to supply 1 sample for testing?
Yes, Of course. We can provide 1 sample Terminal PDA for your
testing.
Question 4: What's the total price for 1 sample?
As a manufacturer of barcode scanner terminal PDA,the more you buy,
the cheaper it'll be.
The sample price is a little bit higher than the common wholesale
price excluding the freight fee.
Question 5: Are you a manufacturer of Handheld PDA?
Yes, we are a R&D orientation China Listed Company, mainly
producing industrial PDA Terminal Hardware and as a software
solutions supplier with over 8 years' OEM/ODM experience. We are
also cooperating with Foxconn Factory.
Question 6: What kind of services do you support ?
We provide you Free SDK and Technical Support for your Barcode
Scanner.
We also provide ODM/OEM Customization Services based to your
demands.
We support 13 months Warranty for all the device and 6 months for
the batteries. Exend warranty, it costs 10% at the first year, and
15% for the second year.
Question 7: What's for payment term and delivery term ?
It's generally 30%-100% TT in advance for all orders. Meanwhile,
Paypal or West Union is acceptable.
FOB Shenzhen as Trade Term.
Question 8: Who are your customers?
Our products have been sold to worldwide,especially market in
South/North America, Europe, Asia, Africa Mid-east, etc.
The market share is increasing quickly every year and we get more
and more positive feedbacks from our customers.
