USB Windows Handheld PDA Devices QR Code Portable Barcode Scanner
Bluetooth GPS
Quick Details of QR code scanner:
1, 4.5inch high-definition IPS LCD capacitive touch screen to meet
your visual enjoyment.
2, 5MP camera with high definition ,it's easy to collect all kinds
of image information
3, Support 1D/2D barcode scanning,LF/HF/UHF RFID/fingerprint
reading, terminal printer, MSR, PSAM function etc
4, Three Operation System, More Stable and Reliable,provide
complete SDK and technical support to make further app development
easily
Specifications of QR code scanner:
| OS option |
| OS | option 1 | Windows mobile 6.1/6.5 |
| option 2 | WM CE 6 |
| option 3 | Android 4.0 |
| Hardware |
| Core board |
| CPU | TI3715 A8 1Ghz |
| WWLAN | option 1 | without modem |
| option 2 | Huawei MU609 Module: GSM band 850/900/1800/1900MHz, GPRS, EDGE UMTS
850/900/1900/ 2100MHz HSPA ) |
| Phone call &SMS function | NA. (Only supports Internet access.) |
| Memory | Flash ROM | 512MB |
| RAM | 512MB DDR |
| Extend Slot | Micro SD 32G (SDHC) |
| EMMC ROM | OPTION | 4GB ROM |
| Motherboard |
| Display | 4.5inch IPS 854*480 (Without Transflective screen) |
| touch screen | 4-wire resistive |
| Form Factor | Bar type classical PDA,Industrial appearance |
| GPS | UBLOX 6010 |
| Bluetooth | JORJIN WG7310 Bluetooth |
| WiFi | JORJIN WG7310 WiFi (802.11 b/g/n) |
| External Interface | USB HOST/RS232(Customized) |
| Protection class | IP65 |
| Drop resistance level | 1.5m |
| Camera Function | Camera | 5MP Camera |
| Video | Support still image and video capture |
| Keypad | Front | 17 |
| Side | 4 |
| Interface | Mini-USB connector | USB2.0 connection |
| SIM card slot | Yes |
| TF card slot | Yes |
| power jack | Yes |
| Audio Jack | Yes |
| Battery | Type | rechargeable Li-ion battery 4500mAh |
| Standby Time | 500hours |
| Calls Time | Up to 6hours |
| Charging Time | 4 hours |
| Physical Characteristics | Dimension | 175*76*27mm |
| Weight | >400g with battery (according config) |
| Extensions |
| PSAM(Optional) | ISO7816 (SIM card interfance) |
| MSR(Optional) | Compatible with one, two, three track. (without PCI, EMV security
certification.) |
| IC card reder(Optional) | ISO7816 ID-1 |
| Fingerprint reader | option 1 | UPEK TCS1 (meet the FBI’s FIPS-201) |
| option 2 | UPEK TCS2SS |
| Printer(Optional) | 2 inch Direct thermal line printing |
| Far Infrared Meter Reading (Optional) | IEC62056-21(IEC1107) communication protocol |
| zigbee(Optional) | 2.4Ghz |
| RFID | option 1 | LF RFID(134.2khz, ISO11784/11785, FDX-B/HDX) |
| option 2 | LF RFID(125KHz) |
| option 3 | HF RFID(13.56MHz ISO 1443A/B ISO 15693) |
| option 4 | NFC(include 13.56MHz ISO 1443A/B ) |
| option 5 | UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) / ISO18000-6A,B
compatibility in direct mode----with AS3992 shipset |
| option 6 | UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) with R2000 shipset |
| barcode scanner | option 1 | NEWLAND:EM1300(1D barcode reader) |
| option 2 | NEWLAND:EM3000(1D/2D barcode reader) |
| option 3 | Symbol:SE955(1D laser barcode reader) |
| option 4 | HoneyWell:N4313 (1D laser barcode reader) |
| option 5 | Symbol: SE4500(1D&2D barcode reader) |
Product Use of QR code scanner:
We have a strong R&D team for not only hardware but also software, have developed the following solutions for our customers:
- Logistics & Express
- Transportation
- Electric meter readings
- Network community management
- Storage & Distribution
- Petrochemical inspection
- Geomatics & Surveying
- Product tracking
- Health & pharmaceutical industry
- Mobile police service
- Tobacco Logistics
- Fixed-assets management
- Surveying and mapping
- Animal tracking & research
- Retail chain
Advantages of QR code scanner:
8 years' experience of R&D and OEM/ODM services for customers all over the world.
| 1. Price ranges | Factory direct with competitive and wholesale price with different
demands |
| 2. Modules Options | Over 18 kinds of module functions are optional to meet your demands |
| 3. 3 Operation System | 3 OS can be optional: Win Mobile/CE and Android |
| 4. Colors Options | 4 kinds of colors to choose: yellow, green, grey and blue |
| 5. Customizations | Support OEM/ODM services with LOGO or Mainboard for our customers |
| 6. Wide Solutions | It supplies wide and various industrial solutions |
