USB RS232 HF Rfid Handheld Scanner , Industrial RFID Reader 13.56Mhz

Product Categories

Beijing Speedata Technology Co., Ltd

Contact Now

Name: USB RS232 HF Rfid Handheld Scanner Industrial RFID Reader 1356Mhz
Brand: Speedata
Price: 1 USD

Add to Cart

RFID Reader	option 1	LF RFID(134.2khz, ISO11784/11785, FDX-B/HDX)
	option 2	LF RFID(125KHz)
	option 3	HF RFID(13.56MHz ISO 1443A/B ISO 15693)
	option 4	NFC(include 13.56MHz ISO 1443A/B )
	option 5	UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) / ISO18000-6A,B compatibility in direct mode --with AS3992 shipset
	option 6	UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) / ISO18000-6A,B compatibility in direct mode--with R2000 shipset, Long distance reader.
	option 7	UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) -with PR92000 shipset
barcode scanner	option 1	NEWLAND:EM1300(1D barcode reader)
	option 2	NEWLAND:EM3000(1D/2D barcode reader)
	option 3	Symbol:SE955(1D laser barcode reader)
	option 4	HoneyWell:N4313 (1D laser barcode reader)
	option 5	Symbol: SE4500(1D&2D barcode reader)
UHF RFID antanna1		Circularly polarized Dielectric Ceramics
		Antenna model: 40405mm
		Frequency Range: 922.5MHz±8MHz
		Gain(Typical): 2dBi Based on65×65mm ground plane
		Impendence: 50 ohm
UHF RFID antanna2		Circularly polarized Dielectric Ceramics
		Antenna model: 40405mm
		Frequency Range: 865MHz-868MHz
		Gain(Typical): 2dBi Based on65×65mm ground plane
		Impendence: 50 ohm
UHF RFID antanna3		Circularly polarized Dielectric Ceramics
		Antenna model: 35355mm
		Frequency Range: 922.5MHz±8MHz
		Gain(Typical): 2dBi Based on35×35mm ground plane
		Impendence: 50 ohm

OS	Android 5.1	4G Wireless	FDD B1B3B7 TDD B38B39B40
			WCDMA B1B2B5B8
			EVDO BC0 GSM B2B3B5B8
CPU	ARM@Cortex-A53 1.3GHz Quad-core	WWLAN	GSM/GPRS/EDGE:850/900/1800/ 1900mMhz
			UMTS/HSPA:850/900/1900/2100MHz
Memory	8GB ROM+1GB RAM	Interface	1MicroSD/TF, 1Audio Jack, 1Micro USB, 1Power Jack
			USB Host/RS-232 interface (Customized)
Display	4.5’’ IPS 480 * 854 LCD Multi-point touch screen	Camera	Support still image and video capture AF 8MP
Positioning module	GPS/AGPS/Ublox8030	Battery	4500mAh/3.7V or 2250mAh/7.4V
Storage	Micro SD/TF card max.32GB expansion	Quality	3C /FCC /ROHS /IP65 /1.5M drop
Slot	1PSAM, 2SIM	Function Options	1.Barcode scanner:1D/2D
			2.RFID reader:LF/HF/UHF/NFC

			4.DGPS/PSAM/433M/Printer
			5.IC Card reader/MSR/IR Meter reading

USB RS232 Android 5.1 Wireless Card Reader PDA HF RFID Card Reader 13.56Mhz
